Sinotruk HOWO TH7 heavy-duty truck 4X2 automatic transmission tractor truck 480HP460HP
- Power system: Sinotruk MC13.48-50
-
Transmission type: Sinotruk HW12-WY
-
Drive form: 4×2
-
Traction weight: 35 tons
Description
The structure of a tractor is roughly the same as that of a truck. It consists of engine, chassis, car body (or cab) and electrical equipment. Because of the need for towing operation and other reasons, some assemblies and components of tractors are not exactly the same as those of ordinary trucks, especially semi-trailers and tractors used in the field.
HW76 extend cab, one berth, with A/C all steel forward control, 55°hydraulically tiltable to the front,2-arm windscreen wiper system with 3 speeds, laminate windscreen, with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, adjustable roof flap, with stereo radio/cassette recorder, sun visor, and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt.
Technical Parameters
|
Basic Information |
|
|
|
|
Drive type: |
4X2 |
Wheelbase: |
3900mm |
|
engine: |
Sinotruk MC13.48-50 |
Gearbox: |
Sinotruk HW12-WY |
|
Body length: |
6.465 meters |
Body width: |
2.496 meters |
|
Ride height: |
3.85 meters |
Front track: |
2041mm |
|
Rear track: |
1816mm |
Vehicle weight: |
6.8 tons |
|
Total mass: |
18 tons |
Total traction mass: |
35 tons |
|
Maximum speed: |
101km/h |
Market segments: |
Express delivery, port transportation, car transporter |
|
Origin: |
Jinan, Shandong |
Tonnage level: |
Heavy trucks |
|
Remark: |
T7H-2450 cab |
Energy Type: |
diesel fuel |
|
Engine parameters |
|
|
|
|
Engine Model: |
Sinotruk MC13.48-50 |
Engine Brand: |
Sinotruk |
|
Number of cylinders: |
6-cylinder |
Fuel Type: |
diesel fuel |
|
Cylinder arrangement: |
series |
Displacement: |
12.419L |
|
Emission standards: |
National Five |
Maximum horsepower: |
480 horsepower |
|
Maximum output power: |
353kW |
Maximum torque: |
2300N路m |
|
Maximum torque speed: |
1050-1400rpm |
Rated speed: |
1900rpm |
|
Transmission parameters |
|
|
|
|
Gearbox Model: |
Sinotruk HW12-WY |
Gearbox brand: |
Sinotruk |
|
Gear shifting method: |
AMT manual and automatic |
Forward gears: |
12 gears |
|
Number of archives: |
2 |
|
|
|
Cab parameters |
|
|
|
|
Lower berth width: |
750 cm |
Number of passengers allowed: |
3 people |
|
Number of Seat Rows: |
Half |
|
|
|
fuel tank |
|
|
|
|
Fuel tank capacity: |
1400L |
|
|
|
Chassis parameters |
|
|
|
|
Front axle description: |
VPD75ES front axle (disc) |
Rear axle description: |
MCY13JES single rear axle (disc) |
|
Permissible load on front axle: |
6500kg |
Permissible load on rear axle: |
11500kg |
|
tire |
|
|
|
|
Number of tires: |
6 |
Tire specifications: |
315/80R22.5 18PR |
|
Control configuration |
|
|
|
|
ABS anti-lock braking system: |
Yes |
|
